FRONT BRAKE

HANDLEBAR FOR KAWASAKI KFX700

FUEL TANK

Item numbers

130

BOLT-FLANGED, 8X60

130CA-0860 130CA0860

Not available

130

BOLT-FLANGED

130P0860 130P0860

Not available

220

SCREW-PAN-CROS, 5X20

220AB-0520 220AB0520

Not available

220

SCREW-PAN-CROS

220C0520 220C0520

Not available

220A

SCREW-PAN-CROS, 5X25

220AB-0525 220AB0525

Not available

220A

SCREW-PAN-CROS

220C0525 220C0525

Not available

220B

SCREW-PAN-CROSS, 5X35

220AB-0535 220AB0535

Not available

220B

SCREW-PAN-CROS

220C0535 220C0535

Not available

220C

SCREW-PAN-CROS, 6X25

220AB-0625 220AB0625

Not available

220C

SCREW-PAN-CROS, 6X25, BLACK

220C0625 220C0625

Not available

223

SCREW-PAN-WS-CROS, 5X12

223AB-0512 223AB0512

Not available

223

SCREW-PAN-WS-CROS

223C0512 223C0512

Not available

312

NUT-HEX, 6MM, BLACK

312C0600 312C0600

Not available

13168

LEVER, LH

13168-0002 131680002

Not available

13168A

LEVER

13168-1715 131681715

Not available

13271

PLATE, LEVER LOCK

13271-0011 132710011

Not available

13271A

PLATE, LOCK

13271-1259 132711259

Not available

23016

LAMP-ASSY

23016-0001 230160001

Not available

23016

LAMP-ASSY

23016-0002 230160002

Not available

27010

SWITCH, BRAKE

27010-1294 270101294

Not available

39074

LEVER-ASSY-THROTTLE

39074-0001 390740001

Not available

39075

LEVER-THROTTLE

39075-1062 390751062

Not available

43049

PACKING

43049-1088 430491088

Not available

46003

HANDLE, G.GRAY

46003-000-1HN 460030001HN

Not available

46012

HOLDER-HANDLE

46012-1168 460121168

Not available

46019A

GRIP-ASSY, SHIFT CONTROL

46019-0006 460190006

Not available

46019A

GRIP-ASSY, SHIFT CONTROL

46019-1122 460191122

Not available

46075

GRIP

46075-0065 460750065

Not available

46075

GRIP

46075-1210 460751210

Not available

46076

LEVER-ASSY-GRIP, LH

46076-1258 460761258

Not available

46091

HOUSING-ASSY-CONTROL, LH

46091-1848 460911848

Not available

46092

LEVER-GRIP, CHOKE

46092-1217 460921217

Not available

49006

BOOT

49006-1261 490061261

Not available

59441

COVER-HANDLE, BLACK

59441-117-36D 5944111736D

Not available

92009

SCREW, CABLE ADJUST, 8MM

46055003 46055003

Not available

92009

SCREW, CABLE ADJUST, 8MM

92009-1435 920091435

Not available

92009A

SCREW, 6X20

92009-1841 920091841

Not available

92009B

SCREW

92009-1959 920091959

Not available

92015

NUT, CABLE ADJUST LOCK

46056005 46056005

Not available

92015

NUT, CABLE ADJUST LOCK, 8MM

92015-1596 920151596

Not available

92015A

NUT, LOCK, 6MM

92019008 92019008

Not available

92015A

NUT

92015-1829 920151829

Not available

92022

WASHER, 5MM

92022-1837 920221837

Not available

92022A

WASHER, WAVE, 5MM

92022-1838 920221838

Not available

92028

BUSHING

92028-1986 920281986

Not available

92049

SEAL-OIL

92049-1578 920491578

Not available

92066

PLUG

92066-1550 920661550

Not available

92081

SPRING, LOCK RETURN

92081-1358 920811358

Not available

92145

SPRING

92145-1392 921451392

Not available

92150

BOLT

92150-1420 921501420

Not available

92150

BOLT

92153-1919 921531919

Not available

92152

COLLAR

92152-1176 921521176

Not available

92171

CLAMP, CLIP

92171-1095 921711095

Not available

92172

SCREW, 5X20

92172-0078 921720078

Not available

92200

WASHER

92200-1558 922001558

Not available

92200A

WASHER

92200-1559 922001559

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Kawasaki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the HANDLEBAR of your Kawasaki of 2004. Let us know if you have any questions.
