Rear Brake

REAR HUB FOR KAWASAKI KLX300R

Rear Master Cylinder

410

WASHER-PLAIN-SMALL 8MM

410B0800 410B0800

Not available

550

PIN-COTTER 3.0X25

550D3025 550D3025

Not available

11012

CAP AXLE

11012-1581 110121581

Not available

41034

DRUM-ASSY REAR BRAKE

41034-1216 410341216

Not available

41068

AXLE RR

41068-1340 410681340

Not available

42041

SPROCKET-HUB 46T

42041-1381 420411381

Not available

42041A

SPROCKET-HUB 47T

42041-1382 420411382

Not available

42041B

SPROCKET-HUB 48T

42041-1383 420411383

Not available

42041C

SPROCKET-HUB 49T

42041-1384 420411384

Not available

42041D

SPROCKET-HUB 50T

42041-1408 420411408

Not available

42041E

SPROCKET-HUB 45T

42041-1413 420411413

Not available

42041F

SPROCKET-HUB 51T

42041-1428 420411428

Not available

42041G

SPROCKET-HUB 52T

42041-1429 420411429

Not available

92015

NUT 8MM

92015-1432 920151432

Not available

92015A

NUT LOCK 20MM

92015-1770 920151770

Not available

92033

RING-SNAP 42MM

92033-1041 920331041

Not available

92045

BEARING-BALL 6004X8JRLLX23A

92045-1239 920451239

Not available

92049

SEAL-OIL BJNC2 25425

92049-1203 920491203

Not available

92057

CHAIN DID520VL2X110L ENDLESS

92057-1410 920571410

Not available

92143

COLLAR RR AXLE L=22

92143-1259 921431259

Not available

92143A

COLLAR RR BRAKE DRUM L=105

92143-1402 921431402

Not available

92143B

COLLAR RR AXLE RH L=20

92143-1840 921431840

Not available

92150

BOLT SOCKET 8X28

92150-1978 921501978

Not available

92200

WASHER 20.2X36X2

92200-1146 922001146

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Kawasaki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the Rear Hub of your Kawasaki of 1998. Let us know if you have any questions.
