CARBURETOR FOR KAWASAKI KDX200

Rear Master Cylinder

132

BOLT-FLANGED-SMALL

132Y0620 132Y0620

Not available

223

SCREW-PAN-WS-CROS

223C0416 223C0416

Not available

11009

GASKET FLOAT CHAMBER

11009-1716 110091716

Not available

11009A

GASKET CHAMBER CAP

11009-1717 110091717

Not available

13159

CONNECTOR THROTTLE CABLE

13159-1063 131591063

Not available

15001

CARBURETOR-ASSY

15001-1980 150011980

Not available

16002

ADJUSTER-CABLE

16002-1057 160021057

Not available

16004

CAP-CHAMBER

16004-1070 160041070

Not available

16009

NEEDLE-JET R1172K2AFKN

16009-1830 160091830

Not available

16009A

NEEDLE-JET R1173K2AFKP

16009-1831 160091831

Not available

16009B

NEEDLE-JET R1174K2AFKQ

16009-1832 160091832

Not available

16009C

NEEDLE-JET R1175K2AFKR

16009-1833 160091833

Not available

16009D

NEEDLE-JET R1176K2AFKS

16009-1834 160091834

Not available

16014

SCREW-PILOT AIR

16014-1058 160141058

Not available

16016

PLUNGER

16016-1085 160161085

Not available

16021

SCREW-THROTTLE STOP

16021-1161 160211161

Not available

16025

VALVE-THROTTLE CA5

16025-1172 160251172

Not available

16030

VALVE-FLOAT

16030-1057 160301057

Not available

16031

FLOAT

16031-1067 160311067

Not available

16044

CLAMP FLOAT VALVE

16044007 16044007

Not available

16049

COVER-MAIN JET

16049-1051 160491051

Not available

16065

HOLDER-CARBURETOR

16065-1298 160651298

Not available

92015

NUT CABLE ADJUST LOCK

92015-1772 920151772

Not available

92036

RING-SNAP

92036018 92036018

Not available

92037

CLAMP TUBE

92037-1396 920371396

Not available

92037A

CLAMP JET NEEDLE

92037-1401 920371401

Not available

92037B

CLAMP TUBE

92037147 92037147

Not available

92037C

CLAMP

92037-1843 920371843

Not available

92037D

CLAMP HOSE

92037-1969 920371969

Not available

92043

PIN FLOAT

92043-1207 920431207

Not available

92055

RING-O MAIN JET COVER

92055-1167 920551167

Not available

92059

TUBE

92059-1888 920591888

Not available

92059A

TUBE 4X7X420

92059-1896 920591896

Not available

92059B

TUBE 3.5X6.5X330

92059-1897 920591897

Not available

92063

JET-MAIN #155

92063-1366 920631366

Not available

92063A

JET-MAIN #158

92063-1367 920631367

Not available

92063B

JET-MAIN #160

92063-1368 920631368

Not available

92063C

JET-MAIN #162

92063-1369 920631369

Not available

92063D

JET-MAIN #165

92063-1370 920631370

Not available

92064

JET-PILOT #52

92064-1130 920641130

Not available

92064A

JET-PILOT #42

92064-1141 920641141

Not available

92064B

JET-PILOT #45

92064-1142 920641142

Not available

92064C

JET-PILOT #48

92064-1143 920641143

Not available

92064D

JET-PILOT #50

92064-1144 920641144

Not available

92081

SPRING ADJUST SCREW

92081-1555 920811555

Not available

92143

COLLAR THROTTLE VALVE

92143-1201 921431201

Not available

92144

SPRING THROTTLE STOP SCREW

92144-1257 921441257

Not available

92144A

SPRING THROTTLE VALVE

92144-1284 921441284

Not available

92170

CLAMP

92170-1514 921701514

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Kawasaki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the Carburetor of your Kawasaki of 1997. Let us know if you have any questions.
