Front Brake

FRONT FORK FOR KAWASAKI KLX140L

Front Hub

11055

BRACKET CABLE GUIDE

11055-0460 110550460

Not available

44008

PIPE-FORK OUTER LH P.SILVER

44008-0038458 440080038458

Not available

44008A

PIPE-FORK OUTER RH P.SILVER

44008-0039458 440080039458

Not available

44013

PIPE-FORK INNER

44013-0112 440130112

Not available

44022

CYLINDER-FORK

44022-0020 440220020

Not available

44024

CAP-OIL-LOCK

44024-1067 440241067

Not available

44025

RING-FORK PISTON

44025-1065 440251065

Not available

44026

SPRING-FRONT FORK

44026-0116 440260116

Not available

44026A

SPRING-FRONT FORK

44026-1417 440261417

Not available

44029

SEAT-FORK SPRING

44029-1136 440291136

Not available

44037

HOLDER-FORK UNDER P.SILVER

44037-0072458 440370072458

Not available

44039

HOLDER-FORK UPPER

44039-0066 440390066

Not available

44045

GASKET FORK CYLINDER BOLT

44045051 44045051

Not available

44065

BUSHING-FRONT FORK INNER PIPE

44065-1123 440651123

Not available

44065A

BUSHING-FRONT FORK

44065-1133 440651133

Not available

44071

DAMPER-ASSY FORK LH P.SILVER

44071-0466458 440710466458

Not available

44071A

DAMPER-ASSY FORK RH P.SILVER

44071-0467458 440710467458

Not available

49006

BOOT FORK BLACK

49006-005-7BD 490060057BD

Not available

92001

BOLT FORK CYLINDER

92001-1464 920011464

Not available

92026

SPACER

92026-1365 920261365

Not available

92049

SEAL-OIL FORK OUTER TUBE

92049-1524 920491524

Not available

92055

RING-O FORK TOP

92055-1367 920551367

Not available

92072

BAND BOOT

92072-0107 920720107

Not available

92151

BOLT FORK TOP

92151-1262 921511262

Not available

92151A

BOLT FLANGED 8X35

92151-1635 921511635

Not available

92151B

BOLT FLANGED 10X35

92151-1636 921511636

Not available

92152

COLLAR FORK L=150

92152-0643 921520643

Not available

92200

WASHER

92200-1496 922001496

Not available

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Kawasaki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the Front Fork of your Kawasaki of 2013. Let us know if you have any questions.
